Pro Series Grid USB Charger Type A, 2.1A 240V 3-Gang

Item Number: PDLP343HG

Build this product

Where To Buy

Datasheet

Download

Product Dimensions

Width icon

Width38 mm

Height icon

Height78 mm

Embedding depth icon

Embedding depth35 mm

See full specifications

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range

Pro Series

Product or component type

USB charger

Surface finish

matt|textured

Sustainable offer status

Green Premium product

Physical

[ue] rated operational voltage

220/240 V AC 50 Hz

Integrated connection type

3 USB 2.0 type A 5 V DC, maximum load current: 2.1 A

Output current

4.5 A

Device mounting

flush

Device presentation

mechanism with fixing frame

Fixing mode

by screws

Type of packing

polybag

Quantity per set

set of 5

Ambient air temperature for operation

0...45 °C

Ambient air temperature for storage

-5...50 °C

Relative humidity

10...95 %

Protection type

short time short-circuit protection

Number of terminals

3 screw terminal

Screwdriver shape

square drive no 1 (SQ1)|Philips No 2

Clamping connection capacity

1 x 2.5...4 x 2.5 mm² for rigid or stranded cable(s)|3 x 4 mm² for rigid or stranded cable(s)

Wire stripping length

16 mm

Standards

AS/NZ 3112

Height

78 mm

Width

38 mm

Depth

38 mm

Embedding depth

35 mm

Net weight

0.094 kg

Product certifications

RCM

Electrical insulation class

class II

Ik degree of protection

IK08

Ip degree of protection

IP21

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant with Exemptions

Rohs exemption information

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Environmental disclosure

ENVPEP2211014_V1

Circularity profile

N/A

Material

Material

PC (polycarbonate)|PP (polypropylene)|ABS (acrylonitrile butadiene-styrene)

Others

Commercial status history

SESA65410 | Thu Apr 18 23:26:00 EDT 2024 | From Import Local | From 08 to 14

Package 1 bare product quantity

1

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

3.6 cm

Package 1 width

7.8 cm

Package 1 length

11.6 cm

Package 1 weight

102.56 g
Show all specifications

Documents & downloads

hide show
Filter items

  • All

  • Certificates (MSDS)

RCM Certificate of Approval (Conformity)
ZIP

RCM Certificate of Approval (Conformity)

VERSION

6.0

DATE

23 Feb 2024

REVISION

6.0

DOWNLOAD (ZIP) 146.3 KB
