EVlink Pro AC Metal Enclosure IP66, Pedestal Mount In Metallic Kit Enclosure, For 25mm² To 35mm² Cable

EVlink Pro AC Metal Enclosure IP66, Pedestal Mount In Metallic Kit Enclosure, For 25mm² To 35mm² Cable

Item Number: EVA1RFKES

Datasheet

Product Dimensions

Width icon

Width270 mm

Height icon

Height360 mm

Depth icon

Depth180 mm

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range

EVlink

Product or component type

enclosure

Physical

Range compatibility

EVlink EVlink Pro AC EVB3 charging station

Mounting mode

assembled

Provided equipment

<ul><li>1 mounting plate</li><li>2 DIN rail</li><li>4 fixing bracket</li><li>3 cable gland</li></ul>

Height

360 mm

Width

270 mm

Depth

180 mm

Net weight

3.4 kg

Ip degree of protection

IP66

Ik degree of protection

IK09

Ambient air temperature for operation

-30...70 °C

Eu rohs directive

Compliant with Exemptions

Rohs exemption information

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Environmental disclosure

ENVPEP110704EN

Circularity profile

N/A

Others

Life cycle assessment data

No

If one of the deliverables is not relevant please give the reason

Accessories

Package 1 bare product quantity

1

Package 2 bare product quantity

40

Product name

EVlink Pro AC Metal

Poles description

3P + N

Localisation on device

on lower part

[us] rated supply voltage

<ul><li>380...415 V AC 50/60 Hz</li><li>220...240 V AC 50/60 Hz</li></ul>

Earthing system

<ul><li>TT</li><li>TN-S</li><li>TN-C-S</li><li>IT</li><li>compatible IT with additional isolation transformer on the power supply</li></ul>

Bar length

240 mm

Mounting plate description

Telequick perforated

Cable entry number

<ul><li>2 cable gland for M32</li><li>1 cable gland for M12</li></ul>

Cable cross section

25...35 mm²

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

20.000 cm

Package 1 width

29.000 cm

Package 1 length

38.000 cm

Package 1 weight

3.266 kg

Unit type of package 2

P12

Number of units in package 2

40

Package 2 height

109.000 cm

Package 2 width

80.000 cm

Package 2 length

120.000 cm

Package 2 weight

154.000 kg

Green premium status for reporting

Green Premium product

Scip number

a18cb304-12b9-4d34-8ea6-7f2f757726a8

Product contributes to saved and avoided emissions

No
