PDL General Accessories Mounting Plate Architrave 25mm | White

Item Number: PDL560WH

Where To Buy

Datasheet

PDF datasheet

Download

Product Dimensions

Width icon

Width79 mm

Height icon

Height33 mm

Depth icon

Depth25 mm

See full specifications

Barcode

Qty UoM EAN Colour
-
-
-
See all

Specifications

Design

Range of product

PDL General Accessories

Product or component type

mounting plate

Colour tint

white

Surface finish

glossy

Physical

Quantity per set

  • set of 200
  • set of 10

Type of packing

carton

Installation direction

vertical

Device mounting

surface

Height

33 mm

Width

79 mm

Depth

25 mm

Fixing center

62 mm

Cable entry

  • 4 x 16 mm knock-out
  • 4 TPS knock-out cable entry

Ambient air temperature for operation

-10...40 °C

Reach free of svhc

Yes

Toxic heavy metal free

Yes

Mercury free

Yes

Rohs exemption information

Yes

Environmental disclosure

ENVPEP2310013_V1

Eu rohs directive

Pro-active compliance (Product out of EU RoHS legal scope)

Reach regulation

Free of Substances of Very High Concern above the threshold

Reach regulation

Free of Substances of Very High Concern above the threshold

China rohs regulation

Product out of China RoHS scope

Eu rohs directive

Compliant

China rohs regulation

Pro-active China RoHS declaration (out of China RoHS legal scope)

Material

Material

PC (polycarbonate)

Others

Legacy weee scope

In

Package 1 bare product quantity

1

Package 2 bare product quantity

10

Average percentage of recycled plastic content

0 %

Outside of Europe

Weee label

N/A

Weee applicability

Component

Weee exclusion rationale

Component not in scope – non independent function

Warranty duration(in months) bmecat

18

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

2.5 cm

Package 1 width

3.4 cm

Package 1 length

8 cm

Package 1 weight

25.3 g

Unit type of package 2

BB1

Number of units in package 2

10

Package 2 height

7.7 cm

Package 2 width

12 cm

Package 2 length

19.5 cm

Package 2 weight

253 g

Total lifecycle carbon footprint

0.2 kg CO2 eq.

Carbon footprint of the manufacturing phase [a1 to a3]

0.1284228

Carbon footprint of the manufacturing phase [a1 to a3]

0.1 kg CO2 eq.

Carbon footprint of the distribution phase [a4]

0.003804614

Carbon footprint of the distribution phase [a4]

0 kg CO2 eq.

Carbon footprint of the installation phase [a5]

0.007028846

Carbon footprint of the installation phase [a5]

0 kg CO2 eq.

Carbon footprint of the use phase [b2, b3, b4, b6]

0

Carbon footprint of the use phase [b2, b3, b4, b6]

0 kg CO2 eq.

Sustainable packaging

No

Carbon footprint of the end-of-life phase [c1 to c4]

0.07025557

Carbon footprint of the end-of-life phase [c1 to c4]

0.1 kg CO2 eq.

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A

Total lifecycle carbon footprint

0.20951183

Average percentage of recycled metal content

0 %

Packaging made with recycled cardboard

Yes

Packaging without single use plastic

No

China rohs label

1

End of life manual availability

N/A

Take-back

No

Warranty (in months)

18
