Specifications
Design
Range of product
PDL General Accessories
Product or component type
socket-outlet
Colour tint
white
Surface finish
glossy
Physical
Quantity per set
set of 20
Type of packing
carton
[in] rated current
10 A
[ue] rated operational voltage
250 V AC 50 Hz
Number of gangs
1 gang
Socket number
3
Installation direction
vertical
Device mounting
surface
Ambient air temperature for operation
-10...40 °C
China rohs regulation
Pro-active China RoHS declaration (out of China RoHS legal scope)
Environmental disclosure
ENVPEP1608003_V2
Circularity profile
ENVEOLI1608003_V2
Material
Material
PC (polycarbonate)
Others
Commercial status history
- SESA301466
- Wed Aug 09 19:38:00 EDT 2023
- From Import Local
- From 18 to 19
Package 1 bare product quantity
1
Network number of phases
1 phase
Diameter
67 mm
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
4.7 cm
Package 1 width
6.7 cm
Package 1 length
6.7 cm
Package 1 weight
62 g
