Specifications
Design
Range of product
56 Series™
Product or component type
socket
Colour tint
orange
Surface finish
gloss
Physical
Rated current
16 A
[ue] rated operational voltage
500 V
Pin number
4
Ip degree of protection
IP66
Ambient air temperature for operation
-40...55 °C
Quantity per set
set of 4
Type of packing
carton
Rohs exemption information
Yes
Eu rohs directive
Compliant with Exemptions
China rohs regulation
Product out of China RoHS scope. Substance declaration for your information
Material
Material
PBT (polybutylene terephthalate)
Device composition
round pin
Others
Legacy weee scope
In
Package 1 bare product quantity
1
Weee label
N/A
Outside of Europe
Network frequency
50 Hz
Network number of phases
3 phases
Cable cross section
7...16 mm²
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 weight
0.341 kg
Sustainable packaging
No
Warranty (in months)
18
