56 Series Flush Surround 3-Gang IP66

Home ProductsIndustrial56 SeriesFlush Surround

56 Series Flush Surround 3-Gang IP66 | Grey

Item Number: PDL56FA3GY

Where To Buy

Datasheet

PDF datasheet

Download

Barcode

Qty UoM EAN Colour
-
-
-
See all

Specifications

Design

Range

56 Series

Product brand

Clipsal

Product or component type

surface cover

Colour tint

grey

Surface finish

gloss

Physical

Installation direction

vertical

Length

350 mm

Width

157 mm

Depth

12 mm

Number of gangs

1 x 3 gangs

Mounting mode

surface mounted

Fixing center

84 x 288 mm

Quantity per set

set of 5

Type of packing

plastic bag

Ip degree of protection

IP66

Reach free of svhc

Yes

Toxic heavy metal free

Yes

Mercury free

Yes

Rohs exemption information

Yes

Environmental disclosure

ENVPEP130202EN

Eu rohs directive

Pro-active compliance (Product out of EU RoHS legal scope)

Reach regulation

Free of Substances of Very High Concern above the threshold

China rohs regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Material

Material

PVC (polyvinyl chloride)

Others

Legacy weee scope

In

Weee label

N/A

Weee applicability

Component

Outside of Europe

Average percentage of recycled plastic content

0 %

Package 1 bare product quantity

1

Weee exclusion rationale

Component not in scope – non independent function

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

35 cm

Package 1 width

15.7 cm

Package 1 length

1.2 cm

Package 1 weight

1 kg

Total lifecycle carbon footprint

3 kg CO2 eq.

Carbon footprint of the manufacturing phase [a1 to a3]

3.9453860642123804

Carbon footprint of the manufacturing phase [a1 to a3]

4 kg CO2 eq.

Carbon footprint of the distribution phase [a4]

0.29608593756796786

Carbon footprint of the distribution phase [a4]

0.3 kg CO2 eq.

Carbon footprint of the installation phase [a5]

0.06477026120439328

Carbon footprint of the installation phase [a5]

0.1 kg CO2 eq.

Carbon footprint of the use phase [b2, b3, b4, b6]

0

Carbon footprint of the use phase [b2, b3, b4, b6]

0 kg CO2 eq.

Sustainable packaging

No

Carbon footprint of the end-of-life phase [c1 to c4]

2.4475640247847834

Carbon footprint of the end-of-life phase [c1 to c4]

2 kg CO2 eq.

Pvc free

No

Halogen-free status

Halogen free product

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A

Total lifecycle carbon footprint

2.5978640000000004

Average percentage of recycled metal content

0 %

Packaging made with recycled cardboard

Yes

Packaging without single use plastic

No

Halogen-free status

Halogen free product

Pvc free

No

End of life manual availability

N/A

Take-back

No

Warranty (in months)

18
