56 Series Socket 16A 110V 1-Phase 3-Round Pin IP66 | Yellow
Item Number: PDL56SO316110LEYL
Specifications
Design
Range of product
56 Series™
Product brand
PDL
Product or component type
socket-outlet
Colour tint
grey
Surface finish
gloss
Physical
Quantity per set
set of 4
Type of packing
carton
Installation direction
vertical
Width
95 mm
Height
95 mm
Depth
35 mm
Rated current
16 A
[ue] rated operational voltage
250 V
Number of gangs
1 gang
Pin number
3
Mounting mode
surface mounted
Fixing center
84 x 84 mm
Ip degree of protection
IP66
Ambient air temperature for operation
-40...55 °C
Eu rohs directive
Compliant with Exemptions
Rohs exemption information
Yes
China rohs regulation
Product out of China RoHS scope. Substance declaration for your information
Material
Material
plastic
Device composition
round pin
Others
Commercial status history
SESA301466 | Thu Aug 17 21:46:00 EDT 2023 | From Import Local | From 18 to 19
Package 1 bare product quantity
1
Network frequency
50 Hz
Network number of phases
1 phase
Cable cross section
0.75...10 mm²
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
9.5 cm
Package 1 width
9.5 cm
Package 1 length
3.5 cm
Package 1 weight
260 g
