Specifications
Design
| Range of product | 600 Series |
|---|---|
| Product or component type | time switch |
| Colour tint | grey |
| Surface finish | gloss |
Physical
| Quantity per set | set of 4 |
|---|---|
| Type of packing | carton |
| Control type | electronic |
| Installation direction | vertical |
| Length | 94 mm |
| Width | 94 mm |
| Depth | 58 mm |
| [ue] rated operational voltage | 230...240 V 50 Hz |
| Number of gangs | 1 gang |
| Number of poles | 1 |
| Device mounting | surface |
| Fixing center | 84 mm |
| Ambient air temperature for operation | -10...40 °C |
| Ip degree of protection | IP66 |
| Rohs exemption information | Yes |
| Eu rohs directive | Compliant By Exemption |
Material
| Material | PC (polycarbonate) UV stabilised |
|---|
Documents & downloads
Filter items
-
All
-
Product Brochures
-
Quick Start Guide
-
Declaration of Conformity (Sustainability)
ZIP
56 Series sealing instructions using enclosures to ensure full IP66 installation
VERSION
1.0
DATE
29 Sep 2023
REVISION
1.0
DOWNLOAD (ZIP) 360.3 KB
ZIP
56 Series installation and operating instructions for mechanical timers
VERSION
1.0
DATE
29 Sep 2023
REVISION
1.0
DOWNLOAD (ZIP) 109.2 KB
ZIP
56 Series installation and operating instructions for 56 Series programmable timer - 56TCU
VERSION
1.0
DATE
29 Sep 2023
REVISION
1.0
DOWNLOAD (ZIP) 149.7 KB
