Actassi Cable LAN F/FTP 4P Cat6, Euroclass D 550MHz LSZH 500m

Item Number: VDICD68X218

1 PCE 1

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3606481320346	-
12	P12	73606481320345	-

Specifications

Design

Range	Actassi
Product or component type	copper cable
Colour tint	blue

Physical

Cable shielding type	F/FTP with exclusive patented metallic crossfiller
Type of cable	4 pair cables
Communication network category	6A
Communication port protocol	PoE 15W (Power over Ethernet) PoE+ 30W (Power over Ethernet Plus) 4PPoE 100W (Power over Ethernet)
Communication network type	10GBASE-T
Coupling attenuation	>= 75 dB from 30-100 MHz conforming to IEC 61156-5, ed. 2 type Ib >= 75 - 20 x log10(f / 100) dB from 100-1000 MHz conforming to IEC 61156-5, ed. 2 type Ib
Pulling force	100 N
Awg gauge	23 AWG
Cable outer diameter	7.3 mm
Ambient air temperature for storage	-20...60 °C
Ambient air temperature for operation	-20...60 °C
Standards	ISO/IEC 11801-ed. 3 performance EN 50173-1 performance EN 50174-1 performance ANSI/TIA/EIA-568-C.2 performance IEC 61156-5-ed. 2.1 performance EN 50288-10-1 performance ISO/IEC 14763-2 installation standards EN 50174-2 installation standards IEC 60332-1 flame propagation characteristics IEC 60754-1 IEC 60754-2 acidity of combustion gases IEC 61034 smoke generation
Reach free of svhc	Yes
Toxic heavy metal free	Yes
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP2009015EN
Eu rohs directive	Compliant

Material

Material	solid bare copper: conductor PE (polyethylene): wire insulation metallic crossfiller: screen tinned copper: drain wire PE (polyethylene): sheath

Others

Legacy weee scope	Out
Package 1 bare product quantity	1
Package 2 bare product quantity	12
Average percentage of recycled plastic content	0 %
	At least in Europe
Warranty duration(in months) bmecat	18
Weee label	No
Weee applicability	Component
Weee exclusion rationale	Component not in scope – non independent function
Cable packaging	drum of 500 m
Minimum return loss	Guaranteed: 20.1 dB at 100 MHz typical: 24.2 dB Guaranteed: 17.3 dB at 250 MHz typical: 22 dB Guaranteed: 17.3 dB at 500 MHz typical: 20.3 dB
Attenuation	Guaranteed: 19.1 dB Typical: 17.5 dB @ 100 MHz Guaranteed: 31.1 dB Typical: 28.4 dB @ 250 MHz Guaranteed: 45.3 dB Typical: 41.4 dB @ 500 MHz
Power sum near-end crosstalk [psnext]	Guaranteed: 62.3 dB Typical: 71.0 dB at 100 MHz Guaranteed: 56.3 dB Typical: 64.2 dB at 250 MHz Guaranteed: 51.8 dB Typical: 59.1 dB at 500 MHz
Attenuation to crosstalk ratio far-end [acrf]	Guaranteed: 38 dB Typical: 54.7 dB at 100 MHz Guaranteed: 30 dB Typical: 46.6 dB at 250 MHz Guaranteed: 24 dB Typical: 40.5 dB at 500 MHz
Power sum attenuation crosstalk ratio far-end [psacrf]	35 dB at 100 MHz 27 dB at 250 MHz 21 dB at 500 MHz
Near end crosstalk [next]	Guaranteed: 65.3 dB Typical: 85.5 dB at 100 MHz Guaranteed: 59.3 dB Typical: 83.1 dB at 250 MHz Guaranteed: 54.8 dB Typical: 60.1 dB at 500 MHz
Transfer impedance	<= 10 mOhm/m at 1-10 MHz conforming to IEC 61156-5, ed. 2 (grade 1) <= 30 mOhm/m at 30-30 MHz conforming to IEC 61156-5, ed. 2 (grade 1) <= 60 mOhm/m at 100-100 MHz conforming to IEC 61156-5, ed. 2 (grade 1)
Input impedance	100 Ohm
Maximum loop resistance	143.2 Ohm per 1000 m
Segregation class	class c conforming to EN 50174-2
Maximum resistance unbalance	2 %
Bending radius	minimum bending radius during installation: 8 x overall diameter minimum bending radius after installation: 4 x overall diameter
Euroclass level	Dca s2 d1 a1
Nominal velocity propagation	82 %
Linear resistance	71.6 mΩ/m
Calorific value	595 MJ/km
Cable length	500 m
Cable weight	54 kg / 1 km
Targeted region	Europe
Ambient air temperature for installation	0...50 °C
Directives	2006/95/EC - low voltage directive 305/2011/EU - construction product regulation
Flame retardance	LSZH
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	37.000 cm
Package 1 width	40.000 cm
Package 1 length	40.000 cm
Package 1 weight	29.500 kg
Unit type of package 2	P12
Number of units in package 2	12
Package 2 height	95.000 cm
Package 2 width	80.000 cm
Package 2 length	120.000 cm
Package 2 weight	377.500 kg
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	273 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	185.22948654417513
Carbon footprint of the manufacturing phase [a1 to a3]	185 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	25.234813684527193
Carbon footprint of the distribution phase [a4]	25 kg CO2 eq.
Carbon footprint of the installation phase [a5]	8.572042717013927
Carbon footprint of the installation phase [a5]	9 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	0.04833159175511545
Carbon footprint of the use phase [b2, b3, b4, b6]	0 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	53.55913799043556
Carbon footprint of the end-of-life phase [c1 to c4]	54 kg CO2 eq.
Pvc free	No
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	272.6438125279069
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	No
Packaging without single use plastic	No
Pvc free	No
End of life manual availability	N/A
Take-back	No
Warranty (in months)	18
