Specifications
Design
Range of product
Titanium
Product brand
Clipsal
Colour
external sheath: blue
Sustainable offer status
Green Premium product
Physical
Communication network category
6
Awg gauge
AWG 23
Cable shielding type
UTP
Length
305 m
Ambient air temperature for operation
75 °C
Standards
ANSI/TIA/EIA-568-B|ISO/IEC 11801
Reach regulation
Free of Substances of Very High Concern above the threshold
Reach free of svhc
Yes
Eu rohs directive
Pro-active compliance (Product out of EU RoHS legal scope)
Toxic heavy metal free
Yes
Mercury free
Yes
Rohs exemption information
Yes
China rohs regulation
Pro-active China RoHS declaration (out of China RoHS legal scope)
Environmental disclosure
ENVPEP110217EN
Circularity profile
N/A
Material
Material
conductor: bare copper
Others
Package 1 bare product quantity
1
Cable insulation material
PVC (polyvinyl chloride)
Diameter
0.546...0.556 mm (conductor)
External diameter
6.1 mm
Flame retardance
CM
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
0.0354 cm
Package 1 width
0.0272 cm
Package 1 length
0.0344 cm
Package 1 weight
0.045 kg
