| Legacy weee scope |
Out |
| Package 1 bare product quantity |
1 |
| |
Outside of Europe |
| Warranty duration(in months) bmecat |
18 |
| Weee label |
N/A |
| Minimum return loss |
- Guaranteed: 20.5 dB at 1 MHz
- Guaranteed: 23.5 dB at 4 MHz
- Guaranteed: 25 dB at 8 MHz
- Guaranteed: 25.5 dB at 10 MHz
- Guaranteed: 25.5 dB at 16 MHz
- Guaranteed: 25.5 dB at 20 MHz
- Guaranteed: 24.8 dB at 25 MHz
- Guaranteed: 24.1 dB at 31.25 MHz
- Guaranteed: 22 dB at 62.5 MHz
- Guaranteed: 20.6 dB at 100 MHz
- Guaranteed: 18.5 dB at 200 MHz
- Guaranteed: 17.8 dB at 250 MHz
|
| Attenuation |
- Guaranteed: 2.1 dB @ 1 MHz per 100 m cable
- Guaranteed: 3.8 dB @ 4 MHz per 100 m cable
- Guaranteed: 5.4 dB @ 8 MHz per 100 m cable
- Guaranteed: 6 dB @ 10 MHz per 100 m cable
- Guaranteed: 7.6 dB @ 16 MHz per 100 m cable
- Guaranteed: 8.5 dB @ 20 MHz per 100 m cable
- Guaranteed: 9.6 dB @ 25 MHz per 100 m cable
- Guaranteed: 10.7 dB @ 31.25 MHz per 100 m cable
- Guaranteed: 15.5 dB @ 62.5 MHz per 100 m cable
- Guaranteed: 19.9 dB @ 100 MHz per 100 m cable
- Guaranteed: 29.1 dB @ 200 MHz per 100 m cable
- Guaranteed: 33 dB @ 250 MHz per 100 m cable
|
| Power sum equal level far end crosstalk [pselfext] |
- 65 dB / 100 m at 1 MHz
- 53 dB / 100 m at 4 MHz
- 46.9 dB / 100 m at 8 MHz
- 45 dB / 100 m at 10 MHz
- 40.9 dB / 100 m at 16 MHz
- 39 dB / 100 m at 20 MHz
- 37 dB / 100 m at 25 MHz
- 35.1 dB / 100 m at 31.25 MHz
- 29.1 dB / 100 m at 62.5 MHz
- 25 dB / 100 m at 100 MHz
- 19 dB / 100 m at 200 MHz
- 17 dB / 100 m at 250 MHz
|
| Power sum near-end crosstalk [psnext] |
- Guaranteed: 65 dB at 1 MHz
- Guaranteed: 63.3 dB at 4 MHz
- Guaranteed: 58.8 dB at 8 MHz
- Guaranteed: 57.3 dB at 10 MHz
- Guaranteed: 54.2 dB at 16 MHz
- Guaranteed: 52.8 dB at 20 MHz
- Guaranteed: 51.3 dB at 25 MHz
- Guaranteed: 49.9 dB at 31.25 MHz
- Guaranteed: 45.4 dB at 62.5 MHz
- Guaranteed: 42.3 dB at 100 MHz
- Guaranteed: 37.8 dB at 200 MHz
- Guaranteed: 36.3 dB at 250 MHz
|
| Near end crosstalk [next] |
- Guaranteed: 39.8 dB at 250 MHz
- Guaranteed: 41.3 dB at 200 MHz
- Guaranteed: 45.8 dB at 100 MHz
- Guaranteed: 48.9 dB at 62.5 MHz
- Guaranteed: 53.4 dB at 31.25 MHz
- Guaranteed: 54.8 dB at 25 MHz
- Guaranteed: 56.3 dB at 20 MHz
- Guaranteed: 57.7 dB at 16 MHz
- Guaranteed: 60.8 dB at 10 MHz
- Guaranteed: 62.3 dB at 8 MHz
- Guaranteed: 66.8 dB at 4 MHz
- Guaranteed: 75.8 dB at 1 MHz
|
| Input impedance |
100 Ohm (+/- 6) |
| Wire insulation material |
PE |
| Conductor material |
solid bare copper |
| Cable length |
305 m |
| Unit type of package 1 |
PCE |
| Number of units in package 1 |
1 |
| Package 1 height |
4 cm |
| Package 1 width |
4 cm |
| Package 1 length |
2 cm |
| Package 1 weight |
18700 g |
| Total lifecycle carbon footprint |
0.3 kg CO2 eq. |
| Carbon footprint of the manufacturing phase [a1 to a3] |
0.16274 |
| Carbon footprint of the manufacturing phase [a1 to a3] |
0.2 kg CO2 eq. |
| Carbon footprint of the distribution phase [a4] |
0.0072299 |
| Carbon footprint of the distribution phase [a4] |
0 kg CO2 eq. |
| Carbon footprint of the installation phase [a5] |
0.015364 |
| Carbon footprint of the installation phase [a5] |
0 kg CO2 eq. |
| Carbon footprint of the use phase [b2, b3, b4, b6] |
0.040716 |
| Carbon footprint of the use phase [b2, b3, b4, b6] |
0 kg CO2 eq. |
| Sustainable packaging |
No |
| Carbon footprint of the end-of-life phase [c1 to c4] |
0.095389 |
| Carbon footprint of the end-of-life phase [c1 to c4] |
0.1 kg CO2 eq. |
| Total lifecycle carbon footprint |
0.32143889999999997 |
| Packaging made with recycled cardboard |
Yes |
| China rohs label |
1 |
| End of life manual availability |
N/A |
| Warranty (in months) |
18 |
