Actassi Socket Module Connector RJ45, Cat6A, Shielded 30 Mech

Actassi Socket Module Connector RJ45, Cat6A, Shielded 30 Mech

Item Number: 30RJ45SM6AF

Datasheet

Product Dimensions

Width icon

Width23 mm

Height icon

Height26 mm

Depth icon

Depth41 mm

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Product brand

Clipsal

Range of product

Titanium

Product or component type

modular jack

Physical

Connector type

RJ45

Communication network category

6A

Awg gauge

AWG 24...AWG 22

[in] rated current

2 A

Depth

41 mm

Width

23 mm

Height

26 mm

Reach free of svhc

Yes

Toxic heavy metal free

Yes

Mercury free

Yes

Rohs exemption information

Yes

Environmental disclosure

ENVPEP110122EN

Eu rohs directive

Compliant

Reach regulation

Free of Substances of Very High Concern above the threshold

China rohs regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Material

Material

phosphor bronze

Others

Legacy weee scope

In

Package 1 bare product quantity

1

Package 2 bare product quantity

20

Average percentage of recycled plastic content

0 %

Outside of Europe

Weee label

N/A

Weee applicability

Finished product

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

3.0 cm

Package 1 width

8.0 cm

Package 1 length

6.0 cm

Package 1 weight

38.9 g

Unit type of package 2

BB1

Number of units in package 2

20

Package 2 height

12.6 cm

Package 2 width

15 cm

Package 2 length

18.2 cm

Package 2 weight

20 kg

Sustainable packaging

No

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A

Average percentage of recycled metal content

0 %

Packaging made with recycled cardboard

No

Packaging without single use plastic

No

End of life manual availability

N/A

Take-back

No

Warranty (in months)

18
