Specifications
Design
Range
Actassi
Product or component type
copper front cover
Product compatibility
- S-110 keystone UTP adaptor plate
- S-110 keystone STP adaptor plate
- UTP copper patch panel
- STP copper patch panel
Product destination
patch panel
Physical
Quantity per set
4
Range compatibility
- Actassi Actassi FLEX adaptor plate
- Actassi Actassi FLEX copper patch panel
Connector type
- S-110 keystone UTP jack connector
- S-110 keystone STP jack connector
Type of installation
indoor
Height
44.45 mm
Length
109.5 mm
Width
9.45 mm
Ambient air temperature for operation
0...55 °C
Ambient air temperature for storage
-20...65 °C
Product certifications
UL
Toxic heavy metal free
Yes
Mercury free
Yes
Rohs exemption information
Yes
Environmental disclosure
ENVPEP090710EN
Eu rohs directive
Pro-active compliance (Product out of EU RoHS legal scope)
China rohs regulation
X
Material
Material
plastic RAL 7016
Others
Legacy weee scope
Out
Package 1 bare product quantity
1
At least in Europe
Weee label
No
Product name
Actassi FLEX
Number of rack unit
1U
Number of port
6
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
7 cm
Package 1 width
11.6 cm
Package 1 length
16.1 cm
Package 1 weight
175 g
Sustainable packaging
No
Warranty (in months)
18
