Network Accessories Flex Empty Fiber Panel Actassi
Item Number: ACTFMFXU
This FLEX empty Fiber Panel is in 1U and to be configured with 24 -port for LC duplex (maximum 48 fibres) or 24-port for SC simplex (maximum 24 fibres). It is compatible with modular fiber cassette (12-port LC duplex or 6-port SC simplex) with built-in accessories to support fusion splicing.
Datasheet
Close
Specifications
Design
| Range | Actassi |
|---|---|
| Product or component type | fibre patch panel |
Physical
| Provided equipment | fibre cassette not included |
|---|---|
| Range compatibility |
|
| Mounting support | 19" rack |
| Height | 44.45 mm |
| Length | 482.6 mm |
| Width | 114.5 mm |
| Ambient air temperature for operation | 0...55 °C |
| Ambient air temperature for storage | -20...65 °C |
| Product certifications | UL |
| Toxic heavy metal free | Yes |
| Mercury free | Yes |
| Rohs exemption information | Yes |
| Environmental disclosure | ENVPEP090710EN |
| Eu rohs directive | Compliant |
Material
| Material |
|
|---|
