Specifications
Design
Range
C-Bus
Product brand
Clipsal
Product or component type
dimmer
Device application
control
Physical
Device presentation
basic element
Load type
inductive
Local signalling
LED
Number of channels
2
Mounting support
wall
Ip degree of protection
IP20
Toxic heavy metal free
Yes
Mercury free
Yes
Rohs exemption information
Yes
Environmental disclosure
ENVPEP111268EN
Eu rohs directive
Compliant
China rohs regulation
Pro-active China RoHS declaration (out of China RoHS legal scope)
Others
Legacy weee scope
In
Package 1 bare product quantity
1
At least in Europe
Weee label
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Power consumption in va
2400 VA
Network frequency
47...63 Hz
Nominal output power
2300 W
Size
base: 240 x 202 x 75 mm
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
8 cm
Package 1 width
23.4 cm
Package 1 length
24.5 cm
Package 1 weight
4.4 kg
Sustainable packaging
No
End of life manual availability
ENVEOLI111254EN
Weee label
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Warranty (in months)
18
