Home ProductsSwitches and Sockets2000 SeriesSurround

2000 Series Surround 1 Gang | Black

Item Number: 2000-BK

White Electric 1 PCE 1
Black 1 PCE 1
Dark Blue 1 PCE 1
Red 1 PCE 1
Silver Plated 1 PCE 1

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	9311554187996	WE
10	BB1	9311554215866	WE
100	CAR	19311554128255	WE
1	PCE	9311554187866	BK
10	BB1	9311554215729	BK
100	CAR	19311554128132	BK
1	PCE	9311554260255	DB
10	BB1	9311554133214	DB
100	CAR	29311554260259	DB
1	PCE	9311554187965	RD
10	BB1	9311554215828	RD
100	CAR	19311554128224	RD
1	PCE	9311554188016	SP
10	CRT	9311554215842	SP
100	CAR	19311554160194	SP

Specifications

Design

Range of product	Series 2000
Product brand	Clipsal
Product or component type	cover frame
Surface finish	brilliant

Physical

Mounting position	horizontal
Fixing mode	by click-in
Device mounting	flush
Mounting mode	surface mounting
Type of installation	indoor
Depth	13 mm
Length	116 mm
Width	76 mm
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP120506EN_V2
Reach regulation	Reference contains Substances of Very High Concern above the threshold
China rohs regulation	Product out of China RoHS scope
Eu rohs directive	Compliant By Exemption

Material

Material	plastic

Others

Legacy weee scope	Out
Package 1 bare product quantity	1
Package 2 bare product quantity	10
Average percentage of recycled plastic content	0 %
	Outside of Europe
Warranty duration(in months) bmecat	18
Weee label	N/A
Weee applicability	Component
Weee exclusion rationale	Component not in scope – non independent function
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	1.3 cm
Package 1 width	7.6 cm
Package 1 length	11.6 cm
Package 1 weight	20 g
Unit type of package 2	BB1
Number of units in package 2	10
Package 2 height	11.7 cm
Package 2 width	10.2 cm
Package 2 length	13.8 cm
Package 2 weight	240 g
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	0.1 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	0.0997695006
Carbon footprint of the manufacturing phase [a1 to a3]	0.1 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.0025804243
Carbon footprint of the distribution phase [a4]	0 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.0000910306
Carbon footprint of the installation phase [a5]	0 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	0
Carbon footprint of the use phase [b2, b3, b4, b6]	0 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	0.0031393018
Carbon footprint of the end-of-life phase [c1 to c4]	0 kg CO2 eq.
Pvc free	No
Halogen-free status	Halogen free product
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	0.1055802572
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	Yes
Packaging without single use plastic	No
China rohs label	5
Halogen-free status	Halogen free product
Pvc free	No
End of life manual availability	N/A
Take-back	No
Warranty (in months)	18

Show all specifications
