600 Series Debuzzer Capacitive Fan Controller Module and Grid Plate 3 Speed 1uF and 2uF | White
Item Number: PDL625C31MWH
Datasheet
Close
Specifications
Design
Range of product
600 Series
Product or component type
switch
Colour tint
white
Surface finish
gloss
Physical
Control type
rotary knob
Installation direction
vertical
Length
23 mm
Width
23 mm
[ue] rated operational voltage
230/240 V
Number of gangs
1 gang
Number of poles
1
Mounting mode
front
Fixing center
84 mm
Quantity per set
set of 1
Type of packing
carton
Eu rohs directive
Pro-active compliance (Product out of EU RoHS legal scope)
Eu rohs directive
Compliant
Material
Material
PC (polycarbonate)
Others
Legacy weee scope
In
Package 1 bare product quantity
1
Outside of Europe
Warranty duration(in months) bmecat
18
Weee label
N/A
Network frequency
50 Hz
Network number of phases
1 phase
Cable cross section
- 2 x 2.5...2.5 mm²
- 4 x 1.5...1.5 mm²
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 weight
69.2 g
Sustainable packaging
No
End of life manual availability
ENVEOLI1208008_V1
Warranty (in months)
18
Documents & downloads
hide showFilter items
-
All
-
Product Brochures
-
Quick Start Guide
-
