600 Series Double Switched Socket 10A + Neon Horizontal

600 Series Double Switched Socket 10A + Neon Horizontal | WH

Item Number: PDL695PWH

Socket outlet assembly for horizontal installations. Twin switched socket with neon RCD ON indicator. 600 Series cover and socket grid are included. PDL 600. Colour: White Rated current: 10A. Operating voltage 250V a.c. 50Hz. Note: Requires installation by an appropriately licenced electrician.

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

600 Series

Product or component type

socket-outlet

Colour tint

white

Surface finish

gloss

Sustainable offer status

Green Premium product

Physical

Control type

push-button

Installation direction

horizontal

Width

118 mm

Height

74 mm

Rated current

10 A

[ue] rated operational voltage

250 V

Number of poles

2

Mounting mode

surface mounted

Fixing center

84 mm

Quantity per set

set of 5

Type of packing

carton

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant with Exemptions

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Environmental disclosure

ENVPEP120506EN

Circularity profile

N/A

Material

Material

PC (polycarbonate)

Others

Package 1 bare product quantity

1

Network frequency

50 Hz

Network number of phases

1 phase

Cable cross section

3 x 2.5...2.5 mm²

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

4 cm

Package 1 width

7.5 cm

Package 1 length

12 cm

Package 1 weight

114 g
