600 Series Double Switched Socket 10A RCD 10mA Trip | White
Item Number: PDL695RCD10WH
Socket outlet assembly for vertical installations. Twin switched socket with RCD protection. 600 Series cover and socket grid are included. PDL 600. Colour: White Rated current: 10A. Operating voltage 250V a.c. 50Hz. Note: Requires installation by an appropriately licenced electrician.
Datasheet
Specifications
Design
| Range of product | 600 Series |
|---|---|
| Product or component type | residual current device |
| Surface finish | gloss |
Physical
| Control type | push-button |
|---|---|
| Installation direction | horizontal |
| Width | 118 mm |
| Height | 74 mm |
| Rated current | 10 A |
| [ue] rated operational voltage | 230/240 V |
| Number of poles | 2 |
| Mounting mode | surface mounted |
| Fixing center | 84 mm |
| Quantity per set | set of 1 |
| Type of packing | carton |
| Mercury free | Yes |
| Rohs exemption information | Yes |
| Environmental disclosure | ENVPEP1607004_V2-EN |
| Reach regulation | Free of Substances of Very High Concern above the threshold |
| China rohs regulation | Product out of China RoHS scope |
| Eu rohs directive | Compliant By Exemption |
Material
| Material | PC (polycarbonate) |
|---|
Documents & downloads
-
All
-
Product Brochures
-
Operating Manuals
-
Certificates (MSDS)
-
Declaration of Conformity (Sustainability)
PDL695RCD10WH EU RoHS Directive
VERSION
1.0
DATE
01 Jan 1900
REVISION
1.0
PDL695RCD10WH EU RoHS Directive
VERSION
1.0
DATE
01 Jan 1900
REVISION
1.0
PDL695RCD10WH REACh Regulation
VERSION
1.0
DATE
01 Jan 1900
REVISION
1.0
PDL695RCD10WH REACh Regulation
VERSION
1.0
DATE
01 Jan 1900
REVISION
1.0
Frequently Asked Questions
What is the part number for the replacement cover plate to suit the PDL695RCD10WH or PDL695RCD30WH?
Hide ShowThe cover plate is not commercialized for sale as a separate item, Please contact your local customer support center as it may be able to be ordered as a special order.
