Specifications
Design
Range of product
600 Series
Product or component type
socket
Colour tint
white
Surface finish
gloss
Physical
Installation direction
vertical
Width
74 mm
Height
118 mm
Mounting mode
surface mounted
Fixing center
84 mm
Connector type
IDC connector
Quantity per set
set of 10
Type of packing
carton
Environmental disclosure
ENVPEP1604002
Eu rohs directive
Under investigation
Material
Material
PC (polycarbonate)
Others
Legacy weee scope
In
Package 1 bare product quantity
1
Weee label
N/A
Outside of Europe
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
2.5 cm
Package 1 width
7.5 cm
Package 1 length
11.5 cm
Package 1 weight
0.067 kg
Sustainable packaging
No
End of life manual availability
N/A
Warranty (in months)
18
