Specifications
Design
Range of product
600 Series
Product or component type
switch
Colour tint
white
Surface finish
gloss
Physical
Control type
rotary
Installation direction
- horizontal
- vertical
Rated current
16 A
[ue] rated operational voltage
230/240 V
China rohs regulation
Product out of China RoHS scope. Substance declaration for your information
Material
Material
PC (polycarbonate)
Others
Package 1 bare product quantity
1
Network type
AC
Cable cross section
- 2 x 2.5...2.5 mm²
- 4 x 1.5...1.5 mm²
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
3.7 cm
Package 1 width
2.3 cm
Package 1 length
2.5 cm
Package 1 weight
16.1 g
