Specifications
Design
| Range of product | 600 Series |
|---|---|
| Product or component type | switch |
| Surface finish | gloss |
Physical
| Control type | rocker |
|---|---|
| Installation direction | vertical |
| Length | 23 mm |
| Width | 23 mm |
| Rated current |
|
| [ue] rated operational voltage | 250 V |
| Number of gangs | 1 gang |
| Number of poles | 1 |
| Mounting mode | front |
| Ambient air temperature for operation | -10...40 °C |
| Mercury free | Yes |
| Rohs exemption information | Yes |
| Environmental disclosure | ENVPEP1607003_V2 |
| Reach regulation | Reference contains Substances of Very High Concern above the threshold |
| China rohs regulation | Product out of China RoHS scope |
| Eu rohs directive | Compliant By Exemption |
Material
| Material | PC (polycarbonate) |
|---|
