600 Series Switch 20A 16AX 2-Gang | White

Item Number: PDL682WH

White 1 PCE 1
Black 1 PCE 1

Switch assembly. 600 series cover plate, grid and switch mechanism are included. Suitable for 2-gang installations. Assembled with plate. PDL 600. Colour: White Rated current: 20A / 16AX. Operating voltage 250V a.c. 50Hz Note: Requires installation by an appropriately licenced electrician.

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	9416175078675	WH
1	PCE	9416175080005	BK
10	BB1	9416175247606	BK
100	CAR	19416175080002	BK

Specifications

Design

Range of product	600 Series
Product or component type	switch
Surface finish	gloss

Physical

Control type	rocker
Installation direction	horizontal vertical
Length	118 mm
Width	74 mm
Rated current	20 A 16 AX
[ue] rated operational voltage	250 V
Number of gangs	2 gangs
Number of poles	1
Mounting mode	surface mounted
Fixing center	84 mm
Ambient air temperature for operation	-10...40 °C
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP2407007_V1
Eu rohs directive	Compliant By Exemption

Material

Material	PC (polycarbonate)

Others

Legacy weee scope	In
Package 1 bare product quantity	1
Average percentage of recycled plastic content	0 %
	Outside of Europe
Warranty duration(in months) bmecat	18
Weee label	N/A
Weee applicability	Finished product
Network type	AC
Motor m-rating as3133	M60
Cable cross section	2 x 2.5...2.5 mm² 4 x 1.5...1.5 mm²
Main colour tint	white
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	2.5 cm
Package 1 width	7.5 cm
Package 1 length	12 cm
Package 1 weight	83 g
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	1 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	0.40981119791266624
Carbon footprint of the manufacturing phase [a1 to a3]	0.4 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.5918327072630717
Carbon footprint of the distribution phase [a4]	0.6 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.018399204231494676
Carbon footprint of the installation phase [a5]	0 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	0.0446696459183316
Carbon footprint of the use phase [b2, b3, b4, b6]	0 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	0.1402993101931658
Carbon footprint of the end-of-life phase [c1 to c4]	0.1 kg CO2 eq.
Pvc free	Yes
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	1.20501206551873
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	Yes
Packaging without single use plastic	No
Pvc free	Yes
End of life manual availability	N/A
Take-back	No
Warranty (in months)	18
