Specifications
Design
Range of product
600 Series
Product or component type
switch
Colour tint
white
Surface finish
gloss
Sustainable offer status
Green Premium product
Physical
Control type
rocker
Installation direction
horizontal
Length
118 mm
Width
74 mm
Rated current
20 A|16 AX
[ue] rated operational voltage
250 V
Number of gangs
3 gangs
Number of poles
1
Mounting mode
surface mounted
Fixing center
84 mm
Ambient air temperature for operation
-10...40 °C
Eu rohs directive
Compliant with Exemptions
Mercury free
Yes
China rohs regulation
Product out of China RoHS scope. Substance declaration for your information
Rohs exemption information
Yes
Environmental disclosure
ENVPEP120506EN
Circularity profile
N/A
Material
Material
PC (polycarbonate)
Others
Package 1 bare product quantity
1
Network type
AC
Motor m-rating as3133
M50
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
12.5 cm
Package 1 width
5.4 cm
Package 1 length
8.0 cm
Package 1 weight
145.0 g
