Specifications
Design
Range of product
600 Series
Product or component type
switch
Colour tint
white
Surface finish
gloss
Physical
Control type
rocker
Installation direction
- vertical
- horizontal
Rated current
- 16 A
- 8 AX
- 16 AX
[ue] rated operational voltage
230/240 V
Number of poles
1
China rohs regulation
Product out of China RoHS scope. Substance declaration for your information
Environmental disclosure
ENVPEP120506EN
Circularity profile
N/A
Material
Material
PC (polycarbonate)
Others
Package 1 bare product quantity
1
Network type
AC
Motor m-rating as3133
M50
Cable cross section
- 2 x 2.5...2.5 mm²
- 4 x 1.5...1.5 mm²
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
2.3 cm
Package 1 width
3.17 cm
Package 1 length
2.3 cm
Package 1 weight
0.015 kg
