600 Series Time Delay Switch 250VAC

600 Series Time Delay Switch 250VAC | White

Item Number: PDL632WH

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

600 Series

Product or component type

time switch

Colour tint

white

Surface finish

gloss

Physical

Control type

rocker

Installation direction

vertical

Length

118 mm

Width

74 mm

[ue] rated operational voltage

230/250 V

Number of gangs

1 gang

Number of poles

1

Mounting mode

surface mounted

Fixing center

84 mm

Ambient air temperature for operation

-10...40 °C

Quantity per set

set of 1

Type of packing

carton

Eu rohs directive

Pro-active compliance (Product out of EU RoHS legal scope)

Material

Material

PC (polycarbonate)

Others

Package 1 bare product quantity

1

Network frequency

50 Hz

Network number of phases

1 phase

Number of ways

2 ways

Cable cross section

  • 2 x 2.5...2.5 mm²
  • 4 x 1.5...1.5 mm²

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

5 cm

Package 1 width

8 cm

Package 1 length

12 cm

Package 1 weight

0.125 kg
