C2000 Series RCD Protected Twin Switch Socket Outlet 250V, 10A, 30mA RCD

Home ProductsSwitches and SocketsC2000 SeriesRCD Protected Twin Switch Socket Outlet

C2000 Series RCD Protected Twin Switch Socket Outlet 250V, 10A, 30mA RCD | WE

Item Number: C2025RC-WE

Socket outlet assembly for horizontal installations. Twin switched socket with RCD protection. Clipsal C2000. Colour: White Electric Rated current: 10A. Operating voltage 250V a.c. 50Hz Note: Requires installation by an appropriately licenced electrician.

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

Classic Series C2000

Product brand

Clipsal

Surface finish

glossy

Sustainable offer status

Green Premium product

Physical

Control type

ON/OFF button

Number of gangs

2 gangs

Pin number

3

Number of power socket outlets

2

Actuator

switch|rocker

Fixing mode

by screws

Local signalling

without light indicator

Mounting position

horizontal

[ue] rated operational voltage

250 V AC

[in] rated current

10 A

Depth

28 mm

Length

116 mm

Width

76 mm

Fixing center

84 mm

Standards

AS/NZS 3112

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant with Exemptions

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Environmental disclosure

ENVPEP120506EN

Circularity profile

N/A

Material

Material

plastic

Others

Package 1 bare product quantity

1

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

6.0 cm

Package 1 width

10.3 cm

Package 1 length

14.8 cm

Package 1 weight

230.0 g
Show all specifications
