Specifications
Design
Range of product
Metal Plate
Product or component type
switched socket
Product brand
Clipsal
Physical
Control type
ON/OFF button
Number of gangs
1 gang
Pin number
3
Number of power socket outlets
1
Actuator
- rocker
- switch
Fixing mode
by screws
Local signalling
without light indicator
Mounting position
vertical
[ue] rated operational voltage
250 V AC
[in] rated current
10 A
Depth
35 mm
Length
115 mm
Width
70 mm
Fixing center
84 mm
Standards
- AS/NZS 3100
- AS/NZS 3112
- AS/NZS 3133:approval number S/1
China rohs regulation
Pro-active China RoHS declaration (out of China RoHS legal scope)
Environmental disclosure
ENVPEP111024EN
Circularity profile
ENVEOLI110713EN
Material
Material
brass
Others
Commercial status history
- SESA301466
- Thu Aug 17 21:46:00 EDT 2023
- From Import Local
- From 18 to 19
Package 1 bare product quantity
1
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
3.5 cm
Package 1 width
7 cm
Package 1 length
11.5 cm
Package 1 weight
0.2 kg
