Iconic Audio Connector RCA Socket Pair | Translucent
Item Number: 40SPK/2-TN
Iconic audio sockets 40SPK/2-TN provides 2 RCA connectors that clips-in, one red and one black. These flush audio sockets inserts are translucent and glossy, and has its connection on the rear. It is sold in set of 10 and Its dimensions are : 23 mm height, 23 mm width and 21 mm depth.
Specifications
Design
| Range | Clipsal Iconic |
|---|---|
| Product or component type | audio socket |
| Colour tint | translucent |
| Surface finish | glossy |
Physical
| Connector type | RCA |
|---|---|
| Device presentation | mechanism |
| Fixing mode | clip-in |
| Quantity per set | set of 10 |
| Device mounting | flush |
| Socket number | 2 |
| Range compatibility | Clipsal Iconic |
| Connections - terminals | solder terminal (rear) |
| Height | 23 mm |
| Width | 23 mm |
| Depth | 21 mm |
| Net weight | 0.012 kg |
| Reach free of svhc | Yes |
| Toxic heavy metal free | Yes |
| Mercury free | Yes |
| Rohs exemption information | Yes |
| Environmental disclosure | ENVPEP1905004EN |
| Reach regulation | Free of Substances of Very High Concern above the threshold |
| China rohs regulation | Product out of China RoHS scope |
| Eu rohs directive | Compliant |
Material
| Material | PC (polycarbonate) |
|---|---|
| Contacts material | gold plated |
