Pro Series Cover Plate Quad Swiched Socket 10A Horizontal

Home ProductsSwitches and SocketsPro SeriesCover Plate Quad Swiched Socket

Pro Series Cover Plate Quad Swiched Socket 10A Horizontal | Extra Vivid White

Item Number: PDLP395H4C-XW

Decorative clip-on skin. For quad switched sockets. Suitable for horizontal installations. PDL Pro Series. Colour: Black Used with 10A rated sockets

Datasheet

Product Dimensions

Width icon

Width212 mm

Height icon

Height78 mm

Depth icon

Depth9 mm

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range

Pro Series

Product or component type

cover frame

Colour tint

black (BK)

Product destination

switched socket

Surface finish

glossy

Sustainable offer status

Green Premium product

Physical

Type of packing

polybag

Range compatibility

Pro Series switched socket

Number of rocker

4

Number of power socket outlets

4

[in] rated current

10 A

Installation direction

horizontal

Fixing mode

clip-on

Height

78 mm

Width

212 mm

Depth

9 mm

Net weight

0.032 kg

Ambient air temperature for operation

0...45 °C

Relative humidity

10...95 %

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Pro-active compliance (Product out of EU RoHS legal scope)

Rohs exemption information

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Environmental disclosure

ENVPEP2309004EN

Circularity profile

N/A

Material

Material

PC (polycarbonate): window|ABS (acrylonitrile butadiene-styrene): skin

Others

Package 1 bare product quantity

1

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

0.9 cm

Package 1 width

7.8 cm

Package 1 length

21.2 cm

Package 1 weight

39.05 g
