Standard Series Socket Outlet Auto Switched, Horizontal Mount, 10A, Double Pole | White Electric
Item Number: 10DWP-WE
Datasheet
Close
Specifications
Design
Range of product
Standard Series
Product or component type
socket-outlet
Product brand
Clipsal
Physical
Quantity per set
set of 1
Local signalling
without light indicator
Device mounting
flush
[in] rated current
10 A
[ue] rated operational voltage
250 V AC
Depth
26 mm
Length
93 mm
Width
82 mm
Fixing center
70 x 54 mm
Number of poles
2
Standards
- AS/NZS 3112
- AS 3100
- AS 3109
- AS/NZS 3122:approval number S/1
Ip degree of protection
IP44
Reach regulation
Reference contains Substances of Very High Concern above the threshold
Eu rohs directive
Compliant
Toxic heavy metal free
Yes
Mercury free
Yes
Rohs exemption information
Yes
China rohs regulation
Pro-active China RoHS declaration (out of China RoHS legal scope)
Others
Package 2 bare product quantity
5
Package 1 bare product quantity
1
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
2.6 cm
Package 1 width
8.2 cm
Package 1 length
9.3 cm
Package 1 weight
128 g
Unit type of package 2
BB1
Number of units in package 2
5
Package 2 height
12.6 cm
Package 2 width
14.4 cm
Package 2 length
15.6 cm
Package 2 weight
648 g
