Specifications
Design
Range of product
Wilco
Product brand
Clipsal
Physical
Outlet standard description
pin earth
Quantity per set
set of 1
Marking
without marking
Local signalling
without light indicator
Device mounting
flush
Fixing mode
by screws
[in] rated current
10 A
[ue] rated operational voltage
110 V AC
Mercury free
Yes
Rohs exemption information
Yes
Environmental disclosure
ENVPEP120506EN
Eu rohs directive
Compliant with Exemptions
China rohs regulation
Product out of China RoHS scope. Substance declaration for your information
Others
Weee label
N/A
Outside of Europe
Package 1 bare product quantity
1
Legacy weee scope
In
Cover type
complete housing
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 weight
0.06 kg
Sustainable packaging
No
End of life manual availability
N/A
Warranty (in months)
18
