Specifications
Design
| Range of product | 500 Series |
|---|---|
| Product or component type | residual current device |
| Colour tint | white |
| Surface finish | gloss |
Physical
| Quantity per set |
|
|---|---|
| Type of packing | polybag |
| Control type | push-button |
| Installation direction | vertical |
| Width | 56 mm |
| Height | 92 mm |
| [ie] rated operational current | 20 A |
| [ue] rated operational voltage | 230/240 V 50 Hz |
| Number of poles | 2 |
| Device mounting | surface |
| Fixing center | 84 mm |
| Clamping connection capacity | 3 x 2.5 mm² |
| Ambient air temperature for operation | -10...40 °C |
| Mercury free | Yes |
| Rohs exemption information | Yes |
| Reach regulation | Reference contains Substances of Very High Concern above the threshold |
| China rohs regulation | Product out of China RoHS scope |
| Eu rohs directive | Compliant By Exemption |
Material
| Material | PC (polycarbonate) |
|---|
Documents & downloads
Filter items
-
All
-
Product Brochures
-
Operating Manuals
-
