Specifications
Design
Range of product
PDL General Accessories
Product or component type
socket-outlet
Colour tint
white
Surface finish
glossy
Physical
Quantity per set
set of 5
Type of packing
carton
[in] rated current
10 A
[ue] rated operational voltage
250 V AC 50 Hz
Number of gangs
2 gangs
Socket number
3
Installation direction
vertical
Device mounting
surface
Ambient air temperature for operation
-10...40 °C
Reach free of svhc
Yes
Eu rohs directive
Compliant
Toxic heavy metal free
Yes
Mercury free
Yes
Rohs exemption information
Yes
China rohs regulation
Pro-active China RoHS declaration (out of China RoHS legal scope)
Environmental disclosure
ENVPEP110719EN
Circularity profile
N/A
Material
Material
- PC (polycarbonate)
- plastic
Others
Package 1 bare product quantity
1
Network number of phases
1 phase
Diameter
67 mm
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
4.5 cm
Package 1 width
6.5 cm
Package 1 length
6.5 cm
Package 1 weight
0.062 kg
