56 Series Switch Cover 1-Gang 2-Aperture IP66 -Suits 300 Modules

Home ProductsIndustrial56 SeriesSwitch Cover

56 Series Switch Cover 1-Gang 2-Aperture IP66 -Suits 300 Modules | Chemical Resistant White

Item Number: PDL56MO3002LERW

Where To Buy

Datasheet

PDF datasheet

Download

Barcode

Qty UoM EAN Colour
-
-
-
See all

Specifications

Design

Range of product

56 Series™

Product or component type

cover

Colour tint

grey

Surface finish

gloss

Physical

Installation direction

vertical

Width

107 mm

Height

101 mm

Number of gangs

1 gang

Mounting mode

surface mounted

Fixing center

63.6 x 63.6 mm

Ip degree of protection

IP66

Quantity per set

set of 8

Type of packing

carton

Mercury free

Yes

Rohs exemption information

Yes

Environmental disclosure

ENVPEP2506007EN

Eu rohs directive

Pro-active compliance (Product out of EU RoHS legal scope)

Reach regulation

Reference contains Substances of Very High Concern above the threshold

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Material

Material

ABS (acrylonitrile butadiene-styrene)

Others

Legacy weee scope

In

Package 1 bare product quantity

1

Average percentage of recycled plastic content

0 %

Outside of Europe

Weee label

N/A

Weee applicability

Component

Weee exclusion rationale

Component not in scope – non independent function

Diameter

39 mm

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

4.2 cm

Package 1 width

9.6 cm

Package 1 length

9.6 cm

Package 1 weight

216.0 g

Sustainable packaging

No

Pvc free

Yes

Halogen-free status

Product contains halogen above thresholds

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A

Average percentage of recycled metal content

0 %

Packaging made with recycled cardboard

Yes

Packaging without single use plastic

No

Halogen-free status

Product contains halogen above thresholds

Pvc free

Yes

End of life manual availability

N/A

Take-back

No

Warranty (in months)

18
