56 Series Switched Socket 20A 250V 3-Round Pin 2-Gang 2-Pole IP66

Home ProductsIndustrial56 SeriesSwitched Socket

56 Series Switched Socket 20A 250V 3-Round Pin 2-Gang 2-Pole IP66 | Grey

Item Number: PDL56CV320LEGY

Where To Buy

Datasheet

PDF datasheet

Download

Barcode

Qty UoM EAN Colour
-
-
-
See all

Specifications

Design

Range of product

56 Series

Product or component type

switched socket

Colour tint

grey

Surface finish

gloss

Physical

Control type

rotary

Installation direction

vertical

Rated current

20 AX

[ue] rated operational voltage

250 V

Number of gangs

2 gangs

Pin number

3

Number of poles

2

Ip degree of protection

IP66

Fixing center

84 x 180 mm

Device mounting

surface

Width

95 mm

Height

191 mm

Quantity per set

set of 2

Type of packing

carton

Mercury free

Yes

Rohs exemption information

Yes

Eu rohs directive

Compliant with Exemptions

Reach regulation

Reference contains Substances of Very High Concern above the threshold

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Material

Material

plastic

Device composition

round pin

Others

Legacy weee scope

In

Package 1 bare product quantity

1

Average percentage of recycled plastic content

0 %

Outside of Europe

Weee label

N/A

Weee applicability

Finished product

Dimension type

cover only

Network frequency

50 Hz

Motor m-rating as3133

M150

Network number of phases

1 phase

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

6.5 cm

Package 1 width

9.5 cm

Package 1 length

19 cm

Package 1 weight

457 g

Sustainable packaging

No

Pvc free

No

Halogen-free status

Halogen free product

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A

Average percentage of recycled metal content

0 %

Packaging made with recycled cardboard

Yes

Packaging without single use plastic

No

Halogen-free status

Halogen free product

Pvc free

No

Take-back

No

Warranty (in months)

18
Show all specifications

Documents & downloads

hide show
Filter items

  • All

  • Product Brochures

  • Certificates (MSDS)

  • Declaration of Conformity (Sustainability)

Important: Some software files may need a mySchneider or Club login to download.
56 Series Brochure
ZIP

56 Series Brochure

VERSION

1.0

DATE

29 Sep 2023

REVISION

1.0

DOWNLOAD (ZIP) 3.9 MB
Schneider, 56CV series switched sockets, Certificate, RCM, Global Mark Pty LTD
