Lighting LED downlight 750lm, 3K/4K/6K, white

Lighting LED downlight 750lm, 3K/4K/6K, white

Item Number: CLITPDL1C3

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range

Clipsal

Product or component type

downlight

Device application

lighting

Market segment

  • residential
  • commercial

Colour tint

white

Warranty

3-Year

Physical

Device mounting

recessed ceiling

Type of installation

indoor/outdoor

Rated power in w

7 W

[ue] rated operational voltage

230 V AC 50 Hz

Load type

dimmable LED

Quantity per set

1

Width

110 mm

Depth

55 mm

Net weight

0.2 kg

Ip degree of protection

IP44

Ambient air temperature for operation

-10...25 °C

Relative humidity

10...95 % non-condensing

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant with Exemptions

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Environmental disclosure

ENVPEP2305020

Circularity profile

ENVEOLI2305020

Others

Commercial status history

  • SESA65076
  • Fri Sep 15 02:47:00 EDT 2023
  • From Unitary Local
  • From 02 to 08

Packaging without single use plastic

No

Packaging made with recycled cardboard

No

Package 2 bare product quantity

24

Package 1 bare product quantity

1

Main colour tint

white

Shape

round

Light source

LED

Luminous flux

  • 750 lm 3000 K warm white
  • 750 lm 4000 K cool white
  • 750 lm 6000 K day light

Colour rendering index

Ra=80

Bulb lifespan

50000 h

Beam angle

90 °

Cut-out dimensions

90 mm

Targeted country

  • Australia
  • New Zealand

Insulation contact rating

IC-4

Unified glare rating

< 22

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

9 cm

Package 1 width

13 cm

Package 1 length

13 cm

Package 1 weight

264 g

Unit type of package 2

CAR

Number of units in package 2

24

Package 2 height

30 cm

Package 2 width

27.5 cm

Package 2 length

54 cm

Package 2 weight

6.972 kg

Take-back

No

Take-back

No

Product contributes to saved and avoided emissions

No

Recycled metal content at cr level

0

Removable battery

N/A

Carbon footprint (kg.eq.co2 per cr, total life cycle)

320.311249

Global warming ; total life cycle​

320 kg CO2 eq.

Minimum percentage of recycled plastic content

0
