Home ProductsNetwork ConnectivityActassiS-110 Connector

Actassi S-110 Connector RJ45 Keyst One Unshielded Cat6 Shutter | White Electric

Item Number: VDIB17346UWE

White Electric 1 PCE 1
Black 1 PCE 1

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3606489513030	WE
24	BB1	13606489513037	WE
192	S03	43606489513038	WE
4608	P12	73606489513039	WE
1	PCE	3606489512989	BK
24	BB1	13606489512986	BK
192	S03	43606489512987	BK

Specifications

Design

Range	Actassi
Product or component type	RJ45 connector
Colour tint	connector housing: white (ABS + PC) shutter: white (ABS + PC) top cover: transparent (PC) IDC cover: green (PC)
Colour code	TIA-568A/B
Product compatibility	RJ45 plug RJ11 plug
Warranty	18 months

Physical

Device presentation	two piece design
Quantity per set	set of 1
[in] rated current	1.5 A at 25 °C
Permissible voltage	1000 V AC/DC peak, between contacts
Contact resistance	20 mOhm
Insulation resistance	initial insulation resistance: > 500 MOhm at 100 V DC
Awg gauge	AWG 24...AWG 23
Mechanical durability	750 cycles
Pin number	8 pins of copper alloy and gold plated conforming to IEC 60603-7
Tool type	punch down tool quick termination tool
Cable outer diameter	0.9...1.4 mm
Cable shielding type	UTP
Communication network category	6
Communication network type	1000BASE-T
Communication port protocol	PoE 15W (Power over Ethernet) PoE+ (Power over Ethernet) PoE+ 30W (Power over Ethernet Plus) 4PPoE 100W (Power over Ethernet)
Connections - terminals	insulation displacement contact
Transmission frequency	1...250 MHz
Type of footprint	S-110 keystone
Height	22 mm 0.072 ft
Length	0.12 ft 36 mm
Width	16 mm 0.052 ft
Ambient air temperature for operation	14...140 °F -10...60 °C
Ambient air temperature for storage	-40...158 °F -40...70 °C
Climatic withstand	40/070/21 (21 days)
Product certifications	UL listed
Standards	ANSI/TIA-568-C.2 IEC 60603-7-4 ISO/IEC 11801:2011 Ed.2.2 AS/NZS 3080:2003 UL 1863
Reach free of svhc	Yes
Toxic heavy metal free	Yes
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP1806006_V2-EN
Reach regulation	Free of Substances of Very High Concern above the threshold
China rohs regulation	Product out of China RoHS scope
Eu rohs directive	Compliant

Others

Legacy weee scope	In
Package 1 bare product quantity	1
Package 2 bare product quantity	24
Package 3 bare product quantity	192
Package 4 bare product quantity	4608
Average percentage of recycled plastic content	0 %
	At least in Europe
Warranty duration(in months) bmecat	18
Weee label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Weee applicability	Finished product
Product name	Actassi S-110
Flame retardance	UL94-V0 conforming to UL listed
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	2.200 cm
Package 1 width	10.500 cm
Package 1 length	14.500 cm
Package 1 weight	12.000 g
Unit type of package 2	BB1
Number of units in package 2	24
Package 2 height	13.000 cm
Package 2 width	13.000 cm
Package 2 length	18.000 cm
Package 2 weight	288.000 g
Unit type of package 3	S03
Number of units in package 3	192
Package 3 height	30.000 cm
Package 3 width	30.000 cm
Package 3 length	40.000 cm
Package 3 weight	2.763 kg
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	0.1 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	0.06300058276207077
Carbon footprint of the manufacturing phase [a1 to a3]	0.1 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.0002395412521716013
Carbon footprint of the distribution phase [a4]	0 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.004117134628049143
Carbon footprint of the installation phase [a5]	0 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	0.027913246826698025
Carbon footprint of the use phase [b2, b3, b4, b6]	0 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	0.010585416052586895
Carbon footprint of the end-of-life phase [c1 to c4]	0 kg CO2 eq.
Pvc free	Yes
Halogen-free status	Halogen free product
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	0.10585592152157644
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	No
Packaging without single use plastic	No
China rohs label	1
Halogen-free status	Halogen free product
Pvc free	Yes
End of life manual availability	N/A
Take-back	No
Weee label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Warranty (in months)	18
