Specifications
Design
Range of product
PDL Sensors
Product or component type
socket
Colour tint
white
Surface finish
glossy
Sustainable offer status
Green Premium product
Physical
Quantity per set
set of 10|set of 100|set of 1
Type of packing
carton|bag
[ue] rated operational voltage
240 V AC 50 Hz|115/240 V AC 50 Hz
Number of gangs
1 gang
Socket number
3
Installation direction
vertical
Device mounting
surface
Mounting support
panel - thickness: 1-2.5 mm
Height
146 mm
Width
90 mm
Fixing center
120 mm
Connections - terminals
2 x 2.5-2.5 mm² screw terminals
Ambient air temperature for operation
-10...40 °C
Eu rohs directive
Compliant with Exemptions
Mercury free
Yes
Rohs exemption information
Yes
China rohs regulation
Product out of China RoHS scope. Substance declaration for your information
Environmental disclosure
ENVPEP120506EN
Circularity profile
N/A
Material
Material
plastic
Others
Package 1 bare product quantity
1
Rated operational power in va
20 VA
Network number of phases
1 phase
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 weight
672 g
