Specifications
Design
Range of product
600 Series
Product or component type
switch
Surface finish
opaque
Physical
Installation direction
vertical
Length
23 mm
Width
23 mm
Depth
25 mm
[ue] rated operational voltage
240/250 V
Number of gangs
1 gang
Mounting mode
front
Number of terminals
3
Quantity per set
set of 20
Type of packing
crate
Eu rohs directive
Compliant with Exemptions
Mercury free
Yes
Rohs exemption information
Yes
China rohs regulation
Product out of China RoHS scope. Substance declaration for your information
Material
Material
PC (polycarbonate)
Others
Package 1 bare product quantity
1
Light source colour
blue
Network number of phases
1 phase
Cut-out dimensions
25 mm
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
2.3 cm
Package 1 width
2.3 cm
Package 1 length
2.5 cm
Package 1 weight
0.01 kg
