600 Series Switched Socket 10A Vertical 250V | Red
Item Number: PDL691RD
Socket outlet assembly for vertical installations. Single switched socket. 600 Series cover and socket grid are included. PDL 600. Colour: White Rated current: 10A Operating voltage 250V a.c. 50Hz Note: Requires installation by an appropriately licenced electrician.
Datasheet
Specifications
Design
| Range of product | 600 Series |
|---|---|
| Product or component type | switched socket |
| Colour tint | white |
| Surface finish | gloss |
Physical
| Socket number | 1 |
|---|---|
| Rated current | 10 A |
| Control type | rocker |
| Installation direction | vertical |
| Width | 74 mm |
| Height | 118 mm |
| [ue] rated operational voltage | 250 V 50 Hz |
| Device mounting | surface |
| Number of gangs | 1 gang |
| Fixing center | 84 mm |
| Ambient air temperature for operation | -10...40 °C |
| Quantity per set | set of 10 |
| Type of packing | carton |
| Mercury free | Yes |
| Rohs exemption information | Yes |
| Environmental disclosure | ENVPEP120506EN |
| Reach regulation | Reference contains Substances of Very High Concern above the threshold |
| China rohs regulation | Product out of China RoHS scope |
| Eu rohs directive | Compliant By Exemption |
Material
| Material | PC (polycarbonate) |
|---|
