Specifications
Design
Range of product
- Weathershield
- Series WSF
Product brand
Clipsal
Surface finish
brilliant
Physical
Device presentation
basic element
Control type
sliding type
Device mounting
flush
Local signalling
without
[ue] rated operational voltage
250 V AC
Rated current
15 A
Marking
ON
Switch function
- 2-way
- 1-way
Standards
- AS/NZS 3133
- AS 60529
- AS/NZS 3100:approval number S/1
China rohs regulation
Pro-active China RoHS declaration (out of China RoHS legal scope)
Environmental disclosure
ENVPEP130201EN
Circularity profile
N/A
Others
Package 1 bare product quantity
1
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
5.5 cm
Package 1 width
7.7 cm
Package 1 length
8 cm
Package 1 weight
85 g
