WP Series Surface Switch 20A 1-Gang Less Enclosure

WP Series Surface Switch 20A 1-Gang Less Enclosure | GY

Item Number: PDLWSW201LEGY

Datasheet

Product Dimensions

Width icon

Width84 mm

Height icon

Height84 mm

Depth icon

Depth72 mm

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

WP Series

Product or component type

switch

Colour tint

light grey

Surface finish

gloss

Sustainable offer status

Green Premium product

Physical

Switch function

1-pole 2-way

Control type

rocker

Installation direction

horizontal

Width

84 mm

Height

84 mm

Depth

72 mm

Rated current

16 AX|20 A

[ue] rated operational voltage

250 V

Number of gangs

1 gang

Mounting mode

surface mounted

Ip degree of protection

IP56

Clamping connection capacity

4 x 1.5 mm²|2 x 2.5 mm²

Type of packing

carton

Reach regulation

Free of Substances of Very High Concern above the threshold

Reach free of svhc

Yes

Eu rohs directive

Compliant

Toxic heavy metal free

Yes

Mercury free

Yes

China rohs regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Rohs exemption information

Yes

Environmental disclosure

ENVPEP130201EN

Circularity profile

N/A

Material

Material

PC (polycarbonate)

Others

Package 1 bare product quantity

1

Motor m-rating as3133

M60

Network frequency

50 Hz

Product specific application

Suits WE1 or WE1S enclosures

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

4.5 cm

Package 1 width

8.5 cm

Package 1 length

8.5 cm

Package 1 weight

0.072 kg

Unit type of package 2

BB1

Number of units in package 2

6

Package 2 height

86 cm

Package 2 width

128 cm

Package 2 length

175 cm

Package 2 weight

494.3 g
