Actassi S-110 Connector RJ45 Keyst One Unshielded Cat6A

Home ProductsNetwork ConnectivityActassiS-110 Connector

Actassi S-110 Connector RJ45 Keyst One Unshielded Cat6A | White Electric

Item Number: VDIB1736XUWE

Where To Buy

Datasheet

PDF datasheet

Download

Barcode

Qty UoM EAN Colour
-
-
-
See all

Specifications

Design

Range

Actassi

Product or component type

RJ45 connector

Colour tint

  • connector housing: white (ABS + PC)
  • top cover: transparent (PC)
  • IDC cover: green (PC)

Colour code

TIA-568A/B

Warranty

18 months

Physical

Device presentation

two piece design

Quantity per set

set of 1

[in] rated current

1.5 A at 25 °C

Permissible voltage

1000 V AC/DC peak, between contacts

Contact resistance

20 mOhm

Insulation resistance

initial insulation resistance: > 500 MOhm at 100 V DC

Awg gauge

AWG 24...AWG 23

Mechanical durability

750 cycles

Pin number

8 pins of copper alloy and gold plated conforming to IEC 60603-7

Tool type

  • punch down tool
  • quick termination tool

Cable outer diameter

0.9...1.4 mm

Cable shielding type

UTP

Communication network category

6A

Communication network type

10GBASE-T

Communication port protocol

  • PoE+ 30W (Power over Ethernet Plus)
  • PoE+ (Power over Ethernet)
  • PoE 15W (Power over Ethernet)
  • 4PPoE 100W (Power over Ethernet)

Connections - terminals

insulation displacement contact

Transmission frequency

1...500 MHz

Type of footprint

S-110 keystone

Height

  • 0.072 ft
  • 22 mm

Length

  • 0.12 ft
  • 36 mm

Width

  • 16 mm
  • 0.052 ft

Ambient air temperature for operation

  • -10...60 °C
  • 14...140 °F

Ambient air temperature for storage

  • -40...70 °C
  • -40...158 °F

Climatic withstand

40/070/21 (21 days)

Product certifications

UL listed

Standards

  • ANSI/TIA-568-C.2
  • IEC 60603-7-5
  • ISO/IEC 11801:2011 Ed.2.2
  • AS/NZS 3080:2003
  • UL 1863

China rohs regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Environmental disclosure

ENVPEP1806006EN

Circularity profile

N/A

Others

Commercial status history

  • SESA301466
  • Wed Jul 10 21:03:00 EDT 2024
  • From Import Local
  • From 14 to 18

Package 1 bare product quantity

1

Package 2 bare product quantity

24

Package 3 bare product quantity

192

Product name

Actassi S-110

Flame retardance

UL94-V0 conforming to UL listed

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

1.300 cm

Package 1 width

1.300 cm

Package 1 length

1.800 cm

Package 1 weight

12.000 g

Unit type of package 2

BB1

Number of units in package 2

24

Package 2 height

13.000 cm

Package 2 width

13.000 cm

Package 2 length

18.000 cm

Package 2 weight

288.000 g

Unit type of package 3

S03

Number of units in package 3

192

Package 3 height

30.000 cm

Package 3 width

30.000 cm

Package 3 length

40.000 cm

Package 3 weight

2.665 kg

Packaging without single use plastic

No

Packaging made with recycled cardboard

No

Weee

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

Take-back

No

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A
