600 Series Switch Module 2-Way 20A 16AX 1P LIGHT | White
Item Number: PDL681M20LWH
Switch mechanism for 1-gang installations. Single-pole switch. Switch is marked LIGHT. 600 Series mechanism. PDL 600. Colour: White Rated current: 20A / 16AX. Operating voltage 250V a.c. 50Hz Note: Requires installation by an appropriately licenced electrician.
Datasheet
Specifications
Design
| Range of product | 600 Series |
|---|---|
| Product or component type | switch |
| Colour tint | white |
| Surface finish | gloss |
Physical
| Control type | rocker |
|---|---|
| Installation direction |
|
| Length | 23 mm |
| Width | 23 mm |
| Depth | 26 mm |
| Rated current |
|
| [ue] rated operational voltage | 250 V |
| Number of gangs | 1 gang |
| Number of poles | 1 |
| Mounting mode | front |
| Ambient air temperature for operation | -10...40 °C |
| Mercury free | Yes |
| Rohs exemption information | Yes |
| Environmental disclosure | ENVPEP2407007_V1 |
| Reach regulation | Reference contains Substances of Very High Concern above the threshold |
| China rohs regulation | Product out of China RoHS scope |
| Eu rohs directive | Compliant By Exemption |
Material
| Material | PC (polycarbonate) |
|---|
