Iconic Double Switched Socket + Switch 10A Vertical 250V | Vivid White

Item Number: PDL392X-VW

Vivid White 1 PCE 1

Build this product i

This PDL Iconic Twin Switch Vertical Power Point with extra switch has a slim, sleek, clean design that is easy to customise and blends in with your decor.

Where To Buy

Datasheet

Download

Product Dimensions

Width78 mm

Height120 mm

Depth35 mm

See full specifications View cut out specs

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	9416175242380	VW
10	BB1	9416175244834	VW
50	CAR	19416175242387	VW

Specifications

Design

Range	PDL Iconic
Product or component type	switched socket
Surface finish	matt
Surface treatment	untreated

Physical

Device presentation	complete product
Socket number	2
Connections - terminals	screw terminals
Installation direction	vertical
Device mounting	flush
Number of rocker	3
Rated current	10 A
[ue] rated operational voltage	230/240 V
Fixing mode	by screws
Clamping connection capacity	1 x 2.5...4 x 2.5 mm² for stranded cable(s) 1 x 2.5...4 x 2.5 mm² for flexible cable(s) 1 x 2.5...4 x 2.5 mm² for rigid cable(s)
Wire stripping length	16 mm
Net weight	92 g
Ambient air temperature for storage	0...60 °C
Ambient air temperature for operation	0...45 °C
Height	120 mm
Width	78 mm
Depth	35 mm
Toxic heavy metal free	Yes
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP1607004_V2-EN
Reach regulation	Reference contains Substances of Very High Concern above the threshold
China rohs regulation	Product out of China RoHS scope
Eu rohs directive	Compliant By Exemption
Quantity per set	set of 10

Others

Package 1 bare product quantity	1
Legacy weee scope	In
Weee label	N/A
Weee applicability	Finished product
Warranty duration(in months) bmecat	18
Average percentage of recycled plastic content	0 %
	Outside of Europe
Main colour tint	vivid white
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	3.5 cm
Package 1 width	7.8 cm
Package 1 length	9.2 cm
Package 1 weight	92 g
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	10 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	0.7330774097821909
Carbon footprint of the manufacturing phase [a1 to a3]	0.7 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.02637771451303559
Carbon footprint of the distribution phase [a4]	0 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.018707062198008235
Carbon footprint of the installation phase [a5]	0 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	9.4106
Carbon footprint of the use phase [b2, b3, b4, b6]	9 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	0.21585706855472983
Carbon footprint of the end-of-life phase [c1 to c4]	0.2 kg CO2 eq.
Pvc free	No
Halogen-free status	Halogen free product
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	10.404619255047965
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	Yes
Packaging without single use plastic	No
China rohs label	1
Halogen-free status	Halogen free product
Pvc free	No
End of life manual availability	N/A
Take-back	No
Warranty (in months)	18
