Iconic Grid Switched Socket 10A Vertical 250V
Item Number: PDL391G
The 250 V, 10 A PDL Iconic Single Switch Power Point Grid is engineered with safety in mind and with a flush vertical mounting.
Specifications
Design
| Range | PDL Iconic |
|---|---|
| Product or component type | switched socket |
| Surface finish | matt |
| Surface treatment | untreated |
Physical
| Device presentation | mechanism with fixing frame |
|---|---|
| Socket number | 1 |
| Connections - terminals | screw terminals |
| Installation direction | vertical |
| Device mounting | flush |
| Number of rocker | 1 |
| Rated current | 10 A |
| [ue] rated operational voltage | 230/240 V |
| Fixing mode | by screws |
| Clamping connection capacity |
|
| Wire stripping length | 16 mm |
| Net weight | 82 g |
| Ambient air temperature for operation | 0...45 °C |
| Height | 115 mm |
| Width | 71 mm |
| Depth | 31 mm |
| Toxic heavy metal free | Yes |
| Mercury free | Yes |
| Rohs exemption information | Yes |
| Environmental disclosure | ENVPEP1607004_V2-EN |
| Reach regulation | Free of Substances of Very High Concern above the threshold |
| China rohs regulation | Product out of China RoHS scope |
| Eu rohs directive | Compliant |
| Quantity per set | set of 10 |
