600 Series Module Socket Outlet TV 75Ohm F-Type | White

Item Number: PDL628FWH

White 1 PCE 1
Black 1 PCE 1

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	9416175168253	WH
10	BB1	9416175258930	WH
100	CAR	19416175168250	WH
1	PCE	9416175165979	BK
10	BB1	9416175258923	BK
40	CAR	19416175165976	BK

Specifications

Design

Range of product	600 Series
Product or component type	TV coaxial cable
Surface finish	gloss

Physical

Installation direction	vertical
Width	74 mm
Height	118 mm
Mounting mode	surface mounted
Fixing center	84 mm
Marking	TV
Quantity per set	set of 10
Type of packing	carton
Toxic heavy metal free	Yes
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP2406022_V1-EN
Eu rohs directive	Compliant

Material

Material	PC (polycarbonate)

Others

Legacy weee scope	In
Package 1 bare product quantity	1
Average percentage of recycled plastic content	0 %
	Outside of Europe
Warranty duration(in months) bmecat	18
Weee label	N/A
Weee applicability	Finished product
Network number of phases	1 phase
Main colour tint	white
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	3.4 cm
Package 1 width	7.3 cm
Package 1 length	11.7 cm
Package 1 weight	74.3 g
Total lifecycle carbon footprint	4 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	0.40729016528871637
Carbon footprint of the manufacturing phase [a1 to a3]	0.4 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.0395289130931469
Carbon footprint of the distribution phase [a4]	0 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.01516160626976931
Carbon footprint of the installation phase [a5]	0 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	3.055881093217703
Carbon footprint of the use phase [b2, b3, b4, b6]	3 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	0.15699480748331543
Carbon footprint of the end-of-life phase [c1 to c4]	0.2 kg CO2 eq.
Pvc free	No
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	3.6748565853526514
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	Yes
Packaging without single use plastic	No
Pvc free	No
Take-back	No
Warranty (in months)	18

Show all specifications
