600 Series Switch Module 2-Way 20A 16AX 1P Spring return | White

Item Number: PDL681M20PBWH

White 1 PCE 1

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	9416175207976	WH
20	BB1	9416175259678	WH
60	CAR	19416175207973	WH

Specifications

Design

Range of product	600 Series
Product or component type	switch
Surface finish	gloss

Physical

Control type	rocker
Installation direction	vertical horizontal
Length	23 mm
Width	23 mm
Depth	26 mm
Rated current	20 A 16 AX
[ue] rated operational voltage	250 V
Number of poles	1
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP1607003EN
Eu rohs directive	Compliant By Exemption

Material

Material	PC (polycarbonate)

Others

Legacy weee scope	In
Package 1 bare product quantity	1
Average percentage of recycled plastic content	0 %
	Outside of Europe
Weee label	N/A
Weee applicability	Component
Weee exclusion rationale	Component not in scope – non independent function
Network type	AC
Motor m-rating as3133	M60
Cable cross section	2 x 2.5...2.5 mm² 4 x 1.5...1.5 mm²
Main colour tint	white
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	3 cm
Package 1 width	2.3 cm
Package 1 length	2.3 cm
Package 1 weight	14 g
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	3 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	0.09482256
Carbon footprint of the manufacturing phase [a1 to a3]	0.1 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.00223944
Carbon footprint of the distribution phase [a4]	0 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.003398304
Carbon footprint of the installation phase [a5]	0 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	3.173200000000001
Carbon footprint of the use phase [b2, b3, b4, b6]	3 kg CO2 eq.
Sustainable packaging	Yes
Carbon footprint of the end-of-life phase [c1 to c4]	0.030040640000000004
Carbon footprint of the end-of-life phase [c1 to c4]	0 kg CO2 eq.
Pvc free	Yes
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	3.303700944000001
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	Yes
Packaging without single use plastic	Yes
Pvc free	Yes
End of life manual availability	N/A
Take-back	No
Warranty (in months)	18
