Iconic Double Switch Socket + Dual USB Type A+C

Home ProductsSwitches and SocketsPDL IconicDouble Switch Socket + Dual USB

Iconic Double Switch Socket + Dual USB Type A+C | Vivid White

Item Number: PDL395USBAC-VW

Datasheet

Product Dimensions

Width icon

Width78 mm

Height icon

Height120 mm

Depth icon

Depth55 mm

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range

PDL Iconic

Product or component type

switched socket

Surface finish

matt

Physical

Device presentation

complete product

Outlet standard

Australian

Device mounting

flush

Number of power socket outlets

2

Number of rocker

2

Outlet standard description

with earthing contact

Ground lug position

straight 180° position

Fixing mode

by screw

Installation direction

horizontal

Type of packing

polybag

Quantity per set

set of 10

Sale per indivisible quantity

1

Screwdriver shape

square drive no 1 (SQ1)

Clamping connection capacity

1 x 2.5...4 x 2.5 mm² for stranded cable(s)

Wire stripping length

16 mm

Height

120 mm

Width

78 mm

Depth

55 mm

Ambient air temperature for storage

0...60 °C

Ambient air temperature for operation

0...45 °C

Relative humidity

10...95 %

Standards

AS/NZS 3112

Reach free of svhc

Yes

Eu rohs directive

Compliant

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Environmental disclosure

ENVPEP2403023EN

Circularity profile

N/A

Others

Packaging made with recycled cardboard

Yes

Packaging without single use plastic

No

Package 1 bare product quantity

1

Outlet standard deviation

Australian/New Zealand

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

15.2 cm

Package 1 width

7.8 cm

Package 1 length

13.5 cm

Package 1 weight

135 g

Take-back

No

Take-back

No

Product contributes to saved and avoided emissions

No

Recycled metal content at cr level

0

Removable battery

N/A

Global warming ; total life cycle​

13 kg CO2 eq.

Carbon footprint (kg.eq.co2 per cr, total life cycle)

12.72333673

Minimum percentage of recycled plastic content

0
Show all specifications
